Icon 60 Active Wheelchair

Brand:
Product Code:
Icon60

The Icon 60 from Rehasense is a brand new design of lightweight rigid frame active wheelchair designed for daily use. Available in seat widths from 36 to 48 cm. This latest addition to the REHASENS... read more

£1,495.00 with VAT relief
£1,794.00 inc VAT
Free delivery on all orders over £250 Excl. Islands & Scottish Highlands
Any questions? Just Ask
Description

The Icon 60 from Rehasense is a brand new design of lightweight rigid frame active wheelchair designed for daily use. Available in seat widths from 36 to 48 cm. This latest addition to the REHASENSE portfolio which features a lightweight rigid 7000 Series Aluminium Alloy frame and carbon fibre side guard has been designed to enable the user to adjust various elements of the chair to suit their individual needs. The frame length and seat angle are adjustable and for maximum comfort, the backrest – which is foldable to assist with transporting the ICON 60 by car – can be adjusted forward by up to 20˚ or backwards by up to 10˚.

This listing is for a pre-configured, boxed chair and is available in 7 seat widths. A made to order variant is also available if you need a more prescriptive fit of chair with starting price £1895.00 ex VAT

Key features

  • Lightweight rigid frame wheelchair
  • Seat width 36-50 cm, front width 26-40 cm, footrest width 19-33 cm
  • Adjustable seat height (47,5-50 cm) and centre of gravity
  • Max user weight - 120kg
  • Series 7000 Aluminium rigid active wheelchair
  • Multiple of adjustments, seat depth, front and rear seat heights and centre of gravity
  • Angle adjustable front forks
  • 24” Day Light rear wheel with black anodised hand rim, QR axle and pneumatic tyre
  • 4” Alu core castor
  • Angle and height adjustable backrest fitted with a tension adjustable backrest, 3D breathable fabric and seat cushion
  • Low profile scissor lock brakes
  • Carbon fibre side guards
  • Calf strap and under seat zipped pouch included





Technical

Technical Specification

Weight from

Transport weight

SWL

(Safe Weight Limit)

Seat widths

Seat depths

Front frame angle

(in deg)

Seat angles* (in deg)

Range of backrest angle

(in deg)

Front seat heights

Rear seat heights

Footrest height

Center of gravity

adjustment

Backrest height

Rear wheels



9.0 kg



5.8 kg



120 kg



36-48 cm

42-46.5 cm

(1.5 cm increment)



90°

(to the seat)

10°

13°

front: +20°

back: up to -10°

47.5-50 cm

(+ 3-5 cm

cushion)

37.5-45 cm

(+ 3-5 cm

cushion)

4 positions

(1.5 cm increment)

8 positions

(1.3 cm increment)



6 cm of adjustment



2°camber & 1/2″ axle

Standard Configurations

Item number

Product

Seat width

Seat height

Seat depth

Rear wheels

Camber

Axle

Colour

RW060036BK1

ICON 60

36 cm

49-51 cm

42-46.5 cm

24”

1/2″

Black matt

RW060038BK1

ICON 60

38 cm

49-51 cm

42-46.5 cm

24”

1/2″

Black matt

RW060040BK1

ICON 60

40 cm

49-51 cm

42-46.5 cm

24”

1/2″

Black matt

RW060042BK1

ICON 60

42 cm

49-51 cm

42-46.5 cm

24”

1/2″

Black matt

RW060044BK1

ICON 60

44 cm

49-51 cm

42-46.5 cm

24”

1/2″

Black matt

RW060046BK1

ICON 60

46 cm

49-51 cm

42-46.5 cm

24”

1/2″

Black matt

RW060048BK1

ICON 60

48 cm

49-51 cm

42-46.5 cm

24”

1/2″

Black matt

coming soon

ICON 60

50 cm

49-51 cm

42-46.5 cm

24”

1/2″

Black matt
