Josi-Pro Special Needs Pushchair
The Josi-Pro is the latest product from John GMBH, the producers of the leading Josi-Wismi, special needs buggy. The Josi-Pro is a versatile and functional special needs pushchair designed to suppo... read more
Description
The Josi-Pro is the latest product from John GMBH, the producers of the leading Josi-Wismi, special needs buggy. The Josi-Pro is a versatile and functional special needs pushchair designed to support children with mild requirements. The options to adjust the seat depth, seat angle, back rest and foot rest provides optimum support and comfort for the child while the adjustable handlebar height allows attendants to push without stooping. The Josi-Pro comes complete with a sun canopy and can be further enhanced with a wide range of accessories and options.
Click here to visit the manufacturer's online product configurator
Crash Test for Occupied Use in a vehicle
The JOSI-Pro rehab pushchair has been successfully crash tested in accordance with ISO 7176-19 in sizes Small and medium and are therefore approved for safe transport in cars or buses under certain conditions. The approval applies in the tested configuration in accordance with the applicable safety standards (crash test according to DIN EN 12183/12184). Detailed information on safe transport in vehicles can be found in our brochure ‘Passenger Transport’ – available in the download area. Note Size Large is NOT crash tested and can therefore NOT be used as a car seat in a vehicle.
Specification
- Available in 4 sizes (0.75 m-1.85m)
- Crash tested
- Size XS, Small and Medium YES
- Size Large NO
- Aluminium frame, spring-loaded and foldable
- Drum brakes with parking function height and angle adjustable footrest,
- Foldable adjustable seat cushion and upholstered backrest
- 16" rear wheels and 12.5" rigid front wheel
- Seat angle adjustable up to 30° Back adjustment,
- Adjustable handlebar
- Up to 90 kg user weight and 15 kg payload
- Wide range of accessories available
- Customise your Josi-Pro in 6 vibrant colour options
Technical
|
JOSI-pro Article number |
Size XS JP-30001 |
Size S JP-30002 |
Size M JP-30003 |
Size L JP-30004 |
|
Body size |
approx. 75-115 cm |
approx. 105-145 cm |
approx. 125-165 cm |
approx. 150-185 cm |
|
Height: H |
123 cm |
128 cm |
136 cm |
141 cm |
|
Track width: B with track widener or Decon E-Drive 16” |
63 cm 72,5 cm |
63 cm 72,5 cm |
68 cm 77,5 cm |
73 cm 82,5 cm |
|
Inner/seat width: I |
up to 36 cm |
up to 36 cm |
up to 42 cm |
up to 46 cm |
|
Seat height: M (incl. cushion) |
50 cm |
57 cm |
57 cm |
59 cm |
|
Seat depth |
20 - 32 cm |
25 - 40 cm |
30 - 45 cm |
35 - 50 cm |
|
Lower leg length |
up to 32 cm |
up to 36 cm |
up to 42 cm |
up to 47 cm |
|
Total back height |
73 cm |
80 cm |
90 cm |
95 cm |
|
Pack sizes: WDH with lowering: WDH |
55 x 96 x 51 cm not available |
55 x 97 x 60 cm 55 x 97 x 52 cm |
60 x 99 x 64 cm 60 x 99 x 56 cm |
66 x 103 x 64 cm 66 x 103 x 56 cm |
|
Payload / user weight |
max. 35 kg |
max. 50 kg |
max. 70 kg |
max. 90 kg |
|
Additional payload bag |
max. 5 kg |
max. 5 kg |
max. 5 kg |
max. 5 kg |
|
Additional payload platform med. devices |
max. 15 kg |
max. 15 kg |
max. 15 kg |
max. 15 kg |
|
Weight folded frame (with covering) |
17 kg |
18 kg |
19,5 kg |
21,5 kg |
|
Weight common configuration |
23,5 kg |
25,5 kg |
27 kg |
29 kg |
|
Rear wheels, air tyres |
16" / 20" |
16" / 20" |
16" / 20" |
16" / 20" |
|
Air press. back wheels with bike option |
2.0 bar (16" & 20") 2,5-2,8 bar (16“ & 20“) |
2.0 bar (16" & 20") 2,5-2,8 bar (16“ & 20“) |
2.0 bar (16" & 20") 2,5-2,8 bar (16“ & 20“) |
2.0 bar (16" & 20") 2,5-2,8 bar (16“ & 20“) |
|
Wheel camber |
0°/5° with track widener |
0°/5° with track widener |
0°/5° with track widener |
0°/5° with track widener |
|
Seat angle |
approx. 10° - 30° |
approx. 10° - 30° |
approx. 10° - 30° |
approx. 10° - 30° |
|
Back angle |
approx. 110° - 160° |
approx. 110° - 160° |
approx. 110° - 160° |
approx. 110° - 160° |
